ABB 500PSM02 1MRB150015R1 AD-272.100.20-01 AZ:C
Product Overview
The ABB 500PSM02 1MRB150015R1 (AD-272.100.20-01, AZ:C) is a high-efficiency Power Supply Module from ABB’s 500 Series automation system. Designed for industrial control cabinets, this module provides stable, reliable DC power to PLCs, I/O modules, and communication devices in harsh environments.
Product Identification
- Model Number: 500PSM02
- Primary Order Code: 1MRB150015R1
- Alternative Part Numbers: AD-272.100.20-01, AZ:C
- Product Series: ABB 500 Power Supply
- Manufacturer: ABB Automation
- Type: DIN Rail Mount Power Supply
Technical Specifications
Electrical Performance
- Input Voltage: 100-240VAC (50/60Hz) (wide-range)
- Output Voltage: 24VDC ±1% (regulated)
- Output Current: 10A continuous (240W max)
- Efficiency: >93% (energy-saving design)
- Ripple & Noise: <50mVpp (low interference)
- Protections:
- Overload (110% for 5s)
- Short-circuit (auto-recovery)
- Overvoltage (28VDC cutoff)
Mechanical & Environmental
- Dimensions: 125mm × 70mm × 120mm (W×H×D)
- Weight: 850g
- Mounting: 35mm DIN Rail (EN 60715)
- Cooling Method: Convection-cooled (fanless)
- Operating Temperature: -25°C to +70°C
- Storage Temperature: -40°C to +85°C
- Protection Class: IP20 (for cabinet use)
Safety & Compliance
- Safety Standards:
- UL 508 (Industrial Control Equipment)
- IEC/EN 62368-1 (Audio/Video & IT Equipment)
- EMC Performance:
- EN 61000-6-2 (Immunity)
- EN 61000-6-4 (Emission)
- Certifications:
- CE, cULus, RoHS, REACH
Key Features & Benefits
✔ Wide Input Voltage Range (100-240VAC) – Suitable for global applications.
✔ High Efficiency (>93%) – Reduces energy costs & heat generation.
✔ Active PFC (Power Factor Correction) – Complies with EN 61000-3-2.
✔ Redundant Operation Support – Can be paralleled for backup power.
✔ LED Status Indicators – Power OK, Overload, Fault monitoring.
✔ Plug-and-Play Installation – Tool-free DIN rail mounting.
Typical Applications
Industrial Automation
- PLC & DCS system power
- Sensor & actuator supply
- Motor control cabinets
Process Control
- Oil & gas control systems
- Water treatment plants
- Chemical processing
Machinery & Robotics
- CNC machine power distribution
- Robotic controller backup power
- Packaging line control systems
Installation & Wiring Guide
Step 1: Mounting
- Install on 35mm DIN rail (included clip).
- Ensure minimum 50mm clearance for ventilation.
Step 2: Wiring
- AC Input:
- L (Live), N (Neutral), PE (Ground)
- DC Output:
- +V (24VDC), 0V (GND)
Step 3: Power-Up Test
- Verify input voltage (100-240VAC).
- Check output voltage (24VDC ±1%).
- Confirm LED indicators (Green = OK).
Troubleshooting & Diagnostics
Status LEDs
| LED | Color | State | Meaning |
|---|---|---|---|
| PWR | Green | Solid | Normal operation |
| OL | Yellow | Flashing | Overload condition |
| FLT | Red | On | Fault (short-circuit/overvoltage) |
Common Issues & Fixes
