GE Multilin 269PLUS‑100P‑HI Motor Management Relay

Overview

The GE Multilin 269PLUS‑100P‑HI is a high‑performance, microprocessor‑based motor management relay designed for comprehensive protection, monitoring, and control of three‑phase AC motors in critical industrial applications. As part of the 269 Plus series, it offers advanced thermal modeling, rich RTD monitoring, and flexible communication, ideal for medium to large motors in oil & gas, mining, water treatment, and manufacturing. The HI suffix indicates a high‑impedance input configuration for enhanced signal integrity in noisy environments.

Key Features

1. Comprehensive Motor Protection

• Thermal Overload: 8 standard overload curves + user‑defined FlexCurve™; thermal memory lockout.
• Electrical Faults: Short circuit, locked rotor, mechanical jam (rapid trip), phase unbalance/single‑phasing, ground fault, undercurrent, phase reversal.
• Temperature Protection: Up to 10 RTD inputs (stator/bearing/ambient); supports Pt100/Pt1000, Ni120, Cu10; range ‑40°C to +200°C.
• Voltage/Frequency: Undervoltage/overvoltage, overfrequency/underfrequency (meter option).

2. Advanced Monitoring & Control

• Real‑Time Thermal Modeling: Computes motor I²t based on load current; cross‑verifies with RTD feedback for accuracy.
• 48‑Character Backlit LCD: Displays status, current, temperature, fault records; 5 target LEDs.
• Fault & Data Logging: Stores up to 5 trip records; motor statistics (starts, run time, overload events).
• Control Functions: Emergency restart, pre‑trip alarm, single‑shot restart on overload trip; 4 output relays (trip/alarm/auxiliary).

3. Communication & Connectivity

• RS485 Port: Supports Modbus RTU for remote monitoring/configuration.
• EnerVista 269 Software: For easy setup, programming, and maintenance.
• Isolated Analog Outputs: 4 outputs for temperature, current, or thermal capacity signaling.

4. Mechanical & Environmental

• ** Rugged Design**: Dimensions 193 × 125 × 290 mm; weight ~2.6 kg.
• Harsh Environment: Operating temperature ‑40°C to +70°C; conformal coating option; IP54 enclosure.
• Certifications: UL, CSA, CE; compliant with IEC 61850.

Technical Specifications

Applications

• Industrial Motors: Pumps, fans, compressors, conveyors, crushers (mining, oil & gas, water/wastewater, HVAC).
• Critical Equipment: Medium/large three‑phase AC motors requiring precise thermal and electrical protection.
• Harsh Environments: High noise, extreme temperatures, dust, moisture (IP54).
