GE Multilin 339‑E‑P5‑G5‑H‑E‑S‑N‑N‑SN‑D‑N Motor Protection Relay

Overview

The GE Multilin 339‑E‑P5‑G5‑H‑E‑S‑N‑N‑SN‑D‑N is a drawout‑style, microprocessor‑based motor protection relay from the 339 Motor Protection System series, engineered for comprehensive protection, monitoring, and control of low/medium‑voltage three‑phase AC motors in heavy‑duty industrial environments. This specific model (suffix E‑P5‑G5‑H‑E‑S‑N‑N‑SN‑D‑N) features 5A current inputs, standard communications (front USB + rear RS485), high‑impedance inputs, and a basic I/O configuration—ideal for oil & gas, mining, water treatment, and manufacturing applications where reliability and ease of maintenance are critical.



Key Features

1. Comprehensive Motor Protection

• Thermal Overload: Advanced thermal modeling with user‑definable curves; thermal memory retention.
• Electrical Faults: Short circuit (50P/50G), locked rotor, phase unbalance/single‑phasing, ground fault, over/undercurrent (51P/51N), phase reversal, and mechanical jam detection.
• Temperature Protection: Supports RTD inputs (Pt100/Pt1000) for stator/bearing/ambient monitoring (optional on this base model).
• Voltage/Frequency: Undervoltage/overvoltage, overfrequency/underfrequency (metering option).

2. I/O & Connectivity

• Current Inputs: 5A (three‑phase + ground), suitable for standard CTs.
• Contact I/O: 10 digital inputs; 2 Form A + 5 Form C relay outputs (trip/alarm/auxiliary control).
• Communication: Front USB (for local configuration) + rear RS485 (Modbus RTU) for remote monitoring/control.
• Drawout Design: Hot‑swappable module for simplified maintenance, testing, and commissioning—no full system shutdown required.

3. Monitoring & Data Logging

• Display: Backlit LCD with keypad for local status, fault viewing, and configuration.
• Fault Records: Stores multiple trip/alarm events with timestamps; motor run‑time and start‑count statistics.
• EnerVista Software: PC‑based tool for easy setup, programming, and real‑time data visualization.

4. Mechanical & Environmental

• Power Supply: 120–240 V AC / 110–250 V DC (wide‑range, universal input).
• Operating Temp: ‑40°C to +70°C; conformal coating option for harsh environments.
• Certifications: UL, CSA, CE; compliant with IEC 60255.
• Dimensions: ~193 × 125 × 290 mm; weight ~2.6 kg.

Technical Specifications

Applications

• Industrial Motors: Pumps, fans, compressors, conveyors, crushers (mining, oil & gas, water/wastewater, HVAC).
• Critical Equipment: Medium/low‑voltage three‑phase AC motors requiring robust protection and easy maintenance.
• Harsh Environments: High electrical noise, extreme temperatures, dust, and moisture.
