ABB 3ASC25H208 DATX100 Pulse Transformer Board | Industrial Drive Spare Part

Short Description:

Original ABB 3ASC25H208 DATX100 pulse transformer control board for ABB ASTAT / ACS800 drive system. New surplus & fully‑tested used stock, pre‑shipment function test, worldwide export available.

FOB Price: US $100 - 9,999 / Piece

Min.Order Quantity: 1 Piece/Pieces

Supply Ability: 3000Piece/Pieces per Month

Product status: In stock

Brand: ABB

Shipping location: Xiamen

Send email to us Download as PDF

Product Detail

IN Stock, 100% full New! Original Factory Seal !

Product Tags

ABB 3ASC25H208 DATX100 Pulse Transformer Board For ABB Drive System

Product Overview

The ABB 3ASC25H208 (DATX100) is an OEM pulse transformer and signal processing control board designed for ABB ASTAT and ACS800 drive systems. This board handles pulse signal acquisition, galvanic signal isolation and internal bus communication for multi‑drive synchronization, ensuring precise torque and speed control for crane, hoist and heavy‑duty motor applications. It converts field current‑voltage signals into processed pulse signals for drive control logic. On‑board capacitor keeps critical configuration data during short‑term power loss, improving system stability in harsh industrial environments. Widely used for drive cabinet retrofit, emergency spare replacement, maintenance of legacy ABB variable‑frequency drive units. We supply original new surplus stock and pre‑tested used modules. Every unit will complete functional inspection before shipment.

Key Features

OEM pulse transformer board for ABB ASTAT / ACS800 multi‑drive system
Galvanic signal isolation for pulse measurement circuits
On‑board data retention capacitor for power‑fail data protection
Stable internal bus communication for multi‑motor synchronous control
Industrial‑grade anti‑interference performance for heavy‑industry site
Compact slot‑mount structure for drive cabinet installation
Original part number: 3ASC25H208 / DATX100

Compatibility Information

Compatible System

ABB ASTAT series crane motion control system, ABB ACS800 variable frequency drive system

Interchangeable Part Numbers

Main OEM PN：3ASC25H208 (DATX100)
Successor upgrade model：DATX110 (enhanced diagnostic version, not direct drop‑in without firmware check)

Technical Specifications

Item	Specification
Model	DATX100
OEM Order Code	3ASC25H208
Brand	ABB
Product Type	Pulse Transformer Control Board
Applicable Equipment	ASTAT / ACS800 drive cabinet
Power Supply	24 V DC ±10%
Operating Temperature	-25 ℃ ~ +70 ℃
Humidity	5%‑95% non‑condensing
Protection Class	IP20
Weight	approx. 1.03 kg
HS Code	85389099
Mounting	Slot‑mount inside ABB drive cabinet
Origin	Sweden / Switzerland (OEM original)

Applications

Port & factory crane hoist drive system maintenance
Heavy‑industry multi‑motor synchronous drive retrofit
ABB ACS800 variable‑frequency drive spare‑parts replacement
ASTAT motion control cabinet repair & upgrade
Steel‑plant, mining industrial drive emergency spare backup

Product Condition & Supply Terms

Available stock condition： ✅ New Surplus Unused: original stock, no field installation ✅ Used & Fully Tested: removed from working equipment, full function tested before dispatch

All modules pass power‑on and communication function test before delivery. Commercial invoice and packing list can be provided for global customs clearance. Limited warranty for tested spare parts is available.

Technical Resources

Download Datasheet: ABB 3ASC25H208 DATX100 Datasheet PDF

Frequently Asked Questions

What is ABB 3ASC25H208 DATX100 used for?

DATX100 (3ASC25H208) is pulse transformer control board, mainly used for ABB ASTAT crane control and ACS800 drive systems for signal isolation and multi‑drive synchronization control.

Can DATX110 directly replace DATX100?

DATX110 is upgraded successor hardware. It is NOT plug‑and‑drop replacement, hardware revision and drive firmware version must be verified before substitution.
