TRICONEX 3625 Digital Output Module
TRICONEX 3625 Digital Output Module
Overview
The TRICONEX 3625 is a 32-channel high-density digital output (DO) module designed for Tricon/Triconex Safety Instrumented Systems (SIS) (Schneider Electric). It adopts Triple Modular Redundancy (TMR) architecture with three independent, isolated channels, ensuring safe and reliable output control for safety-critical industrial applications. It converts system safety logic commands into 24VDC drive signals for field devices (valves, relays, alarms, pumps), supporting both supervised and non-supervised output modes.
Key Features
- TMR Fault-Tolerant Design: Triple redundant channels; single-point failures do not disrupt operation, delivering 99.999% system availability.
- 32-Channel Output: High-density 32 digital output points, 24VDC nominal, 5A max per channel for direct drive of standard industrial actuators.
- Supervised/Non-Supervised Modes: Configurable output monitoring for fault detection (open/short circuit) in safety loops.
- Isolation & Noise Immunity: Channel-to-channel and channel-to-system electrical isolation, protecting against EMI/RFI interference.
- Fast Response & Diagnostics: Response time <10 ms; onboard self-diagnostics with real-time fault alarms and SOE (Sequence of Events) recording (≤40 ms resolution).
- Safety Certified: Compliant with SIL 3 (IEC 61508), TÜV, FM, and CE standards for safety-critical environments.
- Harsh Environment Operation: Wide temperature range -40°C to +70°C, robust construction for vibration/dust resistance.
- Hot-Swappable: Tool-free installation/replacement, no system downtime during maintenance.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | TRICONEX (Schneider Electric) |
| Model | 3625 |
| Type | Digital Output Module |
| Output Points | 32 |
| Output Voltage | 24VDC (20–30VDC range) |
| Output Current | 5A max per channel |
| Architecture | Triple Modular Redundancy (TMR) |
| Isolation | Channel-to-channel, channel-to-system |
| Response Time | <10 ms (typical) |
| Operating Temperature | -40°C to +70°C |
| Safety Certifications | SIL 3, TÜV, FM, CE |
| Dimensions (L×W×H) | 203 mm × 127 mm × 51 mm |
| Weight | 0.5 kg |
Applications
- Safety Instrumented Systems (SIS): Emergency Shutdown (ESD), safety interlocks, fire & gas (F&G) suppression control.
- Process Industries: Oil & gas, petrochemical, power generation, pharmaceuticals, water treatment.
- Critical Infrastructure: Turbine/compressor control, high-reliability automation, and safety loop actuation.
Compatibility
- Platform: Tricon v9–v10 SIS series systems.
- Communication: Seamless integration with Triconex main processors and I/O modules.
（Click for related modules:3721、3009、4351B、More）
