Overview
The Triconex 3604E is a Triple Modular Redundant (TMR) digital output module for Safety Instrumented Systems (SIS). It provides 16 isolated, non‑commoned 24VDC outputs for driving valves, actuators, and ESD devices in critical processes. Certified for IEC 61508 SIL 3, it ensures fault‑tolerant, fail‑safe operation in high‑risk industries.
Key Features
- TMR Fault Tolerance: Triple‑channel architecture with 2oo3 voting; single‑point faults do not disrupt operation.
- 16‑Channel Output: 16 independent, non‑commoned 24VDC outputs (22–45VDC range); each channel is opto‑isolated.
- SIL 3 Certified: Meets IEC 61508 SIL 3; suitable for ESD, F&G, and process safety interlocks.
- Real‑Time Diagnostics: Per‑channel health monitoring, OVD (Output Voter Diagnostic), and fault logging for predictive maintenance.
- Robust & Compact: Rugged metal enclosure; wide temperature range (‑40°C to +70°C); DIN‑rail mountable.
- Seamless Integration: Native Tricon backplane interface; supports Modbus TCP/IP for system‑wide communication.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Triconex (Schneider Electric) |
| Model | 3604E |
| Type | TMR Digital Output Module |
| Safety Level | IEC 61508 SIL 3 |
| Outputs | 16 × Isolated, Non‑Commoned (24VDC nominal) |
| Voltage Range | 22–45VDC |
| Redundancy | Triple Modular Redundant (TMR), 2oo3 Voting |
| Operating Temp | ‑40°C to +70°C |
| Power | 24VDC (±10%), ≤2.5A |
| Dimensions (H×W×D) | ~190 × 120 × 35 mm |
| Weight | ~3.65 kg |
| Certifications | CE, UL, TUV, RoHS |
Applications
- Oil & Gas: Emergency Shutdown (ESD), valve control, pipeline safety systems.
- Chemical & Petrochemical: Reactor trip, burner management, F&G suppression systems.
- Power Generation: Turbine/boiler protection, grid interlocks, critical load control.
- Pharmaceutical & Manufacturing: Machine safety interlocks, critical process isolation.
