Bently Nevada 3500/60 Vibration Monitor Module | Original Supplier
Original Bently Nevada 3500/60 Vibration Monitoring Module
We supply new & refurbished Bently Nevada 3500/60 module, in stock, fast global shipping with warranty for turbine vibration control system.
Product Overview
The Bently Nevada 3500/60 is a high‑performance vibration monitoring module and a key component of the 3500 series monitoring system. It is specifically designed for online, continuous monitoring of vibration, position, velocity, and acceleration on rotating machinery – including turbines, compressors, fans, pumps, and other critical equipment. The module provides 4 independent, configurable channels that interface directly with Bently Nevada 3300 series proximity probes, velocity sensors, or accelerometers. It delivers reliable, real‑time vibration data to the machinery protection system.
As an original, genuine module, the firmware is unmodified and the hardware revision is fully traceable. It seamlessly integrates with the 3500 rack, power supplies, and communication modules, ensuring API 670 compliance and long‑term operational stability.
Key Features
- 4 Independent Input Channels
Each channel can be independently configured for shaft relative vibration, case vibration, shaft position, eccentricity, speed, or acceleration – flexible adaptation to different measurement points. - Multi‑Sensor Compatibility
Directly supports:- Bently Nevada 3300 NSv/PRo proximity probes (-24 Vdc eddy‑current sensors)
- Velocity sensors (2‑wire or 3‑wire)
- IEPE/ICP accelerometers
Input type is configured via software – no hardware changes required.
- High‑Precision Signal Processing
24‑bit ΔΣ ADC with dynamic range ≥95 dB; built‑in anti‑aliasing filter. Frequency response from 0.1 Hz to 10 kHz (programmable) – meets monitoring requirements from low‑speed to ultra‑high‑speed machines. - Redundancy & Self‑Diagnostics
Hot‑swappable module with channel‑level self‑check, open‑circuit detection, and over‑range indication. Each channel has an “OK” status LED. Faults automatically bypass alarm outputs to prevent false trips. - Flexible Alarming & Output
Four programmable alarm levels (Alert/Danger) per channel with adjustable time delays. Measurement values are transmitted via the 3500 rack backplane to communication modules. Also supports 4‑20 mA recorder outputs (requires 3500/92 or dedicated I/O). - High Reliability
Operating temperature range: -30°C to +65°C; complies with IEC 61000‑4 immunity standards; MTBF > 150,000 hours.
Technical Specifications
| Parameter | Details |
|---|---|
| Channels | 4, fully independent and configurable |
| Sensor Interfaces | - Proximity probe: -24 Vdc (±10%), provides 11 V @ 100 kHz carrier; - Velocity/acceleration: ±30 V input, programmable constant current source (0~8 mA) |
| Measurement Ranges | Displacement: 0~1000 μm (peak‑peak); Velocity: 0~250 mm/s (peak); Acceleration: 0~50 g (peak) |
| Frequency Response | Programmable low‑pass (0.1~500 Hz), high‑pass (0.2~10 kHz), band‑pass and band‑stop filtering |
| Accuracy | ±0.2% full scale (25°C); ±0.5% full scale (full temperature range) |
| Resolution | 24‑bit ADC, effective ≥20 bits |
| Update Rate | ≥20 updates per channel per cycle (supports 5 ms fast output mode) |
| Front Panel | 4 channel status LEDs (OK/Alert/Danger/Bypass); backplane: VME‑compatible bus |
| Power | Supplied by 3500 rack backplane; typical consumption 6.5 W |
| Certifications | CE, ATEX, IECEx, CSA (Class I, Division 2), SIL 2 capable |
Typical Applications
- Steam turbines / generators – shaft vibration, case vibration, differential expansion
- Centrifugal compressors – high‑speed shaft position & bearing vibration
- Fans & pumps – low‑frequency rolling‑element bearing acceleration
- Reciprocating compressors – case vibration & piston rod drop
- Hydraulic turbines – low‑frequency shaft vibration & runout
Why Choose Original (Genuine) Bently Nevada?
| Advantage | Explanation |
|---|---|
| Untampered Firmware | Original firmware is unmodified, ensuring full compatibility with 3500 system versions and no communication errors. |
| Full Traceability | Each module has a unique serial number and factory calibration certificate – traceable to Bently Nevada production line. |
| Long‑Term Support | OEM provides at least 15 years of spare parts availability, reducing maintenance risks. |
| Measurement Accuracy | Counterfeit modules suffer from drift and high noise floor; original guarantees static error <0.1% FS. |
| Certification Validity | Only original modules provide a verifiable SIL 2 functional safety certificate for audits. |
Ordering Information
Base Model: 3500/60-01-00 (Standard, 4 channels, without I/O module)
Configuration Codes (select in order):
| Position | Meaning | Typical Options |
|---|---|---|
| Group 1 | Module type | 60 = Vibration monitoring module |
| Group 2 | Input type | 01 = Universal input (auto‑adapts to proximity/velocity/accel)02 = Proximity only (high noise immunity) |
| Group 3 | Output option | 00 = Backplane bus only11 = 4‑20 mA recorder output (requires external supply) |
| Group 4 | Version | A = StandardB = High accuracy (0.1% FS, for nuclear applications) |
Example model: 3500/60-01-11-A → Universal input + 4‑20 mA output + standard version
Included accessories:
- Front panel dust cover (1)
- Module fixing screws (2)
- Quick installation guide (multi‑language)
Not included: Sensors, extension cables, 3500 rack (order separately).
Related Products
- 3500/40 4‑Channel Position Monitor – dedicated for shaft position
- 3500/92 Communication Gateway – Modbus/DNP3 data forwarding
- 3300 XL 8 mm Proximity Probe – optimal dynamic range with 3500/60
Service & Support
- Technical Support: Free remote configuration assistance and channel assignment consultation.
- Calibration Service: Original ISO 17025 accredited calibration, 12‑month cycle.
- Emergency Supply: 48‑hour expedited shipping for customers at risk of downtime (subject to stock availability).
